Tecnologia
Panoramica tecnica
Telaio
Telaio:
SCOR 6080 Z Alloy Frame | Lower-Link Driven Instant Center Linkage | 180 mm Rear Wheel Travel | 29 / 27.5" Mullet | Boost 148 | SRAM UDH
Forcella:
RockShox ZEB Ultimate RC2 | 190mm Travel | 44mm Rake
Sospensioni
Sospensione Anteriore:
RockShox ZEB Ultimate RC2 | 190mm Travel | 44mm Rake
Sospensione Posteriore:
RockShox Super Deluxe Ultimate RCT | 230 x 65mm
E-System
Unità di Trasmissione:
Bosch Performance CX Smart System
Batteria:
Bosch PowerTube | 750 Wh
Display:
Bosch System Controller BRC3100
Controllo Dell'unità di Trasmissione:
Bosch Mini Remote BRC3300
Caricabatterie:
Bosch 4A Charger
Cockpit
Attacco Manubrio:
Burgtec Enduro MK3 | 31.8mm Bar Bore | 35mm Length | 0° Angle
Piega:
SCOR Alloy Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 9° Backsweep
Nastro:
Burgtec Bartender Pro
Seat
Reggisella:
Bikeyoke Divine | S 125mm | M / L 160mm | XL 185mm Travel | Triggy Alpha lever
Sella:
WTB Silverado Medium Cromoly SL
Freni
Leve Freno / Pinze:
SRAM Code RSC
Dischi freno:
SRAM Centerline | 6-Bolt
Diametro dischi:
220 / 200mm
Ruote
Cerchi:
DT Swiss H 1900 SPLINE | 29 / 27.5" Mullet | 30mm Internal Width | Tubeless ready
Mozzi:
DT Swiss 370 | Ratchet LN Freehub | Straightpull Spoke Interface | Boost spacing
Pneumatici:
Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Assegai 27.5 x 2.5" 3C MaxxTerra DD TR (R)
Informazioni Tubeless:
Tubeless Ready Rims | Tubetype Tires
Informazioni aggiuntive
Sezione max coperture:
Width: 64mm | Diameter: 750mm
Classificazione ASTM:
Level 5
Limite di peso massimale :
130kg
Size | S | M | L | XL |
---|---|---|---|---|
SCOR Size | S-435 | M-459 | L-485 | XL-515 |
Rider Height | 155 - 170 | 165 - 180 | 175 - 190 | 185 - 200 |
Reach | 435 | 459 | 485 | 515 |
Stack | 622 | 625 | 635 | 650 |
BB Drop | 16 | 16 | 16 | 16 |
Chainstay | 435 | 435 | 435 | 435 |
Fork Length | 606 | 606 | 606 | 606 |
Fork Rake | 44 | 44 | 44 | 44 |
Front Center | 798 | 821 | 848 | 876 |
Head Tube | 93 | 96 | 107 | 124 |
Head Tube Angle | 63 | 63 | 63 | 63 |
Seat Angle | 76 | 76 | 76 | 76 |
Seat Tube | 400 | 425 | 440 | 440 |
Standover Height | 733 | 733 | 733 | 733 |
Top Tube | 563 | 592 | 623 | 657 |
Wheelbase | 1224 | 1247 | 1274 | 1302 |
