Tecnologia
Panoramica tecnica
Telaio
Telaio:
SCOR 4060 Full Carbon Frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm Rear Wheel Travel | Fully Guided Internal Cable Routing | Stash Box | Boost 148 | SRAM UDH | Lower ISCG 05 Mount / Chainguide
Forcella:
RockShox Lyrik Ultimate RC2 | 150mm Travel | 44mm Rake
Sospensioni
Sospensione Anteriore:
RockShox Lyrik Ultimate RC2 | 150mm Travel | 44mm Rake
Sospensione Posteriore:
RockShox Super Deluxe Ultimate RCT | 205 x 57.5mm Trunnion
Cockpit
Attacco Manubrio:
Burgtec Enduro MK3 | 31.8mm Bar Bore | 35mm Length | 0° Angle
Piega:
SCOR Carbon Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 7.5° Backsweep
Nastro:
Burgtec Bartender Pro
Seat
Reggisella:
Bikeyoke Divine | S 125mm | M / L 160mm | XL 185mm Travel | Triggy Alpha lever
Sella:
WTB Silverado Titanium | Medium
Gruppo
Guarnitura:
SRAM GX Eagle Carbon Lunar | 170mm Length
Corona:
SRAM GX Eaglerings
Pacco pignoni:
SRAM GX XG-1275 Eagle
Ingranaggi:
10-52T
Catena:
SRAM GX Eagle
Cambio:
SRAM GX Eagle
Comandi:
SRAM GX Eagle Trigger
Rapporti:
1 x 12
Movimento centrale:
DUB Interface
Freni
Leve Freno / Pinze:
SRAM Code RSC
Dischi freno:
SRAM Centerline | 6-Bolt
Diametro dischi:
200mm
Ruote
Cerchi:
DT Swiss XM 1700 SPLINE | 30mm Internal Width | Tubeless ready
Mozzi:
DT Swiss 350 | Ratchet SL Freehub | Straightpull Spoke Interface | Boost spacing
Pneumatici:
Maxxis Assegai 29 x 2.5" 3C MaxxTerra Exo TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra Exo+ TR (R)
Informazioni Tubeless:
Tubeless Ready Rims | Tubetype Tires
Informazioni aggiuntive
Sezione max coperture:
Width: 64mm | Diameter: 750mm
Classificazione ASTM:
Level 4
Limite di peso massimale :
120kg
Size | S | M | L | XL |
---|---|---|---|---|
Rider Height | 155 - 170 | 165 - 180 | 175 - 190 | 185 - 200 |
BB Drop (SLACK) | 31 | 31 | 31 | 31 |
BB Drop (STEEP) | 29 | 29 | 29 | 29 |
BB Height (SLACK) | 338 | 338 | 338 | 338 |
BB Height (STEEP) | 340 | 340 | 340 | 340 |
Chainstay | 433 | 433 | 433 | 433 |
Fork Length | 560 | 560 | 560 | 560 |
Fork Rake | 44 | 44 | 44 | 44 |
Front Center (SLACK) | 765 | 790 | 815 | 845 |
Front Center (STEEP) | 752 | 777 | 802 | 832 |
Head Tube | 87 | 99 | 115 | 127 |
HT Angle (SLACK) | 64.5 | 64.5 | 64.5 | 64.5 |
HT Angle (STEEP) | 65.5 | 65.5 | 65.5 | 65.5 |
Reach (SLACK) | 440 | 465 | 490 | 520 |
Reach (STEEP) | 436 | 461 | 485 | 516 |
Seat Tube | 400 | 425 | 440 | 470 |
ST Angle @750mm Saddle Height (SLACK) | 77 | 77 | 77 | 77 |
ST Angle @750mm Saddle Height (STEEP) | 76.5 | 76.5 | 76.5 | 76.5 |
ST Angle Actual (SLACK) | 69.4 | 69.4 | 69.4 | 69.4 |
ST Angle Actual (STEEP) | 69 | 69 | 69 | 69 |
ST Angle Effective (SLACK) | 78.5 | 78.5 | 78.5 | 78.5 |
ST Angle Effective (STEEP) | 78 | 78 | 78 | 78 |
Stack (SLACK) | 597 | 608 | 622 | 633 |
Stack (STEEP) | 599 | 611 | 625 | 636 |
Stand Over Height (80 in Front of BB) | 752 | 764 | 768 | 784 |
Stand Over Height (Lowest Point) | 714 | 723 | 731 | 741 |
Top Tube (SLACK) | 560 | 589 | 620 | 654 |
Top Tube (STEEP) | 561 | 590 | 621 | 655 |
Wheelbase (SLACK) | 1198 | 1223 | 1248 | 1278 |
Wheelbase (STEEP) | 1185 | 1210 | 1235 | 1265 |
