Specifications

Frameset

Frame: SCOR 4060 full carbon frame | Lower-Link Driven Instant Center Linkage | 160mm rear wheel travel | Fully guided internal cable routing | Stash box | Boost 148 | SRAM Universal Derailleur Hanger | Lower ISCG 05 mount / Chainguide

Suspension

Front Suspension: Öhlins RXF36 m.2 29" Coil | 170mm travel | Independent coil spring | TTX18 damper | Low & high speed compression adjust | Rebound adjust | 44mm rake

Rear Suspension: Öhlins TTX22M | Lightweight coil spring | TTX damper | High & low speed compression & rebound adjust | Pedaling platform | Spring rate lb/in: 365

Cockpit

Handlebar: SCOR Carbon Bar | 31.8mm clamp | 800mm wide | 20mm rise | 5° up sweep - 7.5° back sweep

Stem: Burgtec Enduro MK3 | 3D forged and fully CNC machined | 31.6mm bar bore | 35mm lenght | 0° angle

Seatpost:  Bikeyoke Divine | 185mm | Triggy Alpha lever | Saddle: SqLab 611 Ergowave

Drivetrain

Gears: 1 x 12

Crankset: SRAM GX Eagle Carbon Lunar | 170mm length | 32T chainring | DUB interface

Cassette: SRAM GX Eagle (XG-1275) | 10-52T

Chain: SRAM GX Eagle

Rear Derailleur: SRAM GX Eagle Lunar

Shifters: SRAM GX Eagle Trigger

Brakes

Brake Levers / Calipers: SRAM Code RSC | Rotors: Centerline Rotors, 200mm

Wheels

Wheelset: DT Swiss EX511 | Size: 29"

Hubs: Spank Hex Drive (Front and Rear)

Tires: Michelin Wild Enduro Rear Racing Line | Michelin Wild Enduro Front Racing Line

Tire Clearance: Width: 64mm | Diameter: 750mm

Extras

ASTM Classification: Level 4 | Stash Box | SCOR 4060 X Slicy MySublimistick Frame Protector
